Description
This model 1.5T provides not only conventional pulse sequences and clinical diagnosis functions, but also provides advanced functional applications, for instance, 3D angiography and water imaging.
Specifications
| Magnet center field | 1.5T |
| Magnet Shimmed uniformity | ≤2.0ppm @ 45cm DSV VRMS |
| Magnet size （length*width*height） |
1570 mm× 1866 mm × 2272 mm |
| Magnet Clear bore diameter | 850 mm |
| Magnet weight | <4.0 ton |
| Cold head | RDE-412D4 |
| RF noise attenuation | >90dB |
| Couch route | 2215mm |
| Couch max load | 90kg |
| Couch height | 800mm |
| Gradient Amplitude | 35mT/m |
| Gradient Slew Rate | 135mT/m/ms |
| Gradient Peak voltage | 940V |
| Gradient Peak current | 630A |
| minimum slice thickness | 0.1mm |
| Resonant Frequency | 63.86MHZ |
| RFPA power | 20KW |
| Spectrometer Input frequency range | 15-64MHz |
| Maximum RF receiver channels | 8 |
| RF Maximum Matrix | 1024×1024 |
| V shape longer Spine coil | 16 channel |
| Large plus head coil | 24 channel |
| Large head coil | 16 channel |
- Field Strength : 1.5T
- Magnet Shimmed uniformity : ≤2.0ppm @ 45cm DSV VRMS
- Magnet size (length*width*height) : 1570 mm* 1866 mm * 2272 mm
- Magnet Clear bore diameter : 850 mm
- Magnet weight : <4.0 ton
- RF noise attenuation : >90dB
- Maximum RF receiver channels : 8
- Gradient Amplitude : 35mT/m
- Gradient Slew Rate : 135mT/m/ms
- Resonant Frequency : 63.86MHZ
