Meubon Msl480A Phacoemulsifier — Ultrasonic Cataract Surgery Instrument With Advanced Emulsification Control

Description

The MSL480A Ultrasonic Phaco Emulsifier is an essential tool for cataract extraction surgeries, offering precise performance and reliable operation. Here’s a breakdown of its components and specifications:

• Clinical Application: Specifically designed for cataract extraction surgery.
• Components: Includes the Main Unit, U/S (Phaco Emulsification) Handpiece, Bipolar Cautery Forceps, Vitrector, I/A (Irrigation/Aspiration) Handpiece, Footswitch, and various accessories such as U/S Tip, U/S and/or I/A Sleeves, U/S and/or I/A Test Chamber, and Vitrectomy Irrigation Sleeve.
• Specifications:
  • Phaco Emulsification:
    • Frequency: 40KHz ±20%
    • Vibration Accuracy: Max. 120μm ±20%
    • Stimulating Power Range: 0~100%
    • Pulse Frequency: 1Hz~99Hz
    • Effective Emulsification Time: 1%~99% (≥5ms)
    • Burst Time: 5ms~100ms
    • Max. Vacuum: 66.7kPa (500mmHg)
    • Max. Flow Rate: 40 ml/min
  • High-Frequency Cautery:
    • Frequency: 1MHz ±20%
    • Max. Output Power: 10W ±20% (200Ω Load)
  • Vitrectomy:
    • Cutting Frequency: single mode or (20~600) times/min
    • Max. Vacuum: 66.7kPa (500mmHg)
  • • Maximum Flux Rate: 40 ml/min
  • Irrigation/Aspiration:
    • Vacuum Range: 1mmHg~500mmHg
    • Flow Rate: 1 ml /min~40 ml /min
    • Max. Vacuum: 66.7kPa (500mmHg)
    • Max. Flow Rate: 40 ml/min
    • Reflux Rate: 20 ml/min ±20%

Explore the detailed images of the MSL480A Ultrasonic Phaco Emulsifier to discover its superior design and functionality.
