Description
Experience unparalleled imaging capabilities with our Digital Mobile 500mA X-ray DR System Machine, designed to meet the demands of modern medical facilities with precision and efficiency.
Basic Configuration:
- High-quality combined high-frequency high-voltage generator.
- Color graphical touch LCD control system for intuitive operation.
- Panel detector with free movement for flexible imaging.
- High-quality IPC ensures seamless performance.
- Large size medical LCD display for clear visualization.
- New type mobile column rack for enhanced mobility.
- Symmetric adjustable, wireless ranging rotating collimator with lamp for precise positioning.
- Electric assistance drive system for effortless maneuverability.
- Cable exposure handbrake ensures safety during procedures.
- Wireless remote control exposure device for added convenience.
X-ray Generator:
- 50KW compact x-ray generator with a high frequency of 40KHz.
- Utilizes high technology to reduce radiation exposure.
Unique Power Supply Way:
- Supers capacitor supplies power during photography, ensuring durability.
- Li-Battery supplies power during mechanical movement, enhancing efficiency.
Mechanical Movement:
- Horizon arm can be contracted freely.
- Pillar features electronic up and down movement and 360-degree rotation.
- X-ray tube is rotary and moves left and right with a 90-degree range.
- Collimator can be rotated left and right with a 90-degree range.
- Comprehensive integration control drive for smooth operation.
- Collimator Rotation Range: ±90 degrees.
- Tube Tilt: -10 to +90 degrees.
- Tube Rotation: ±180 degrees.
Software:
- LCD touch screen operation panel for convenient machine control.
- Technical Parameters ensure precise imaging and accurate diagnostics.
After-sale Service:
- 1-year machine warranty.
- Complete operation and maintenance manual provided.
- Site application and service training available.
- Free service hotline for customer support.
Copyright Certificate and Related Patents:
- DR service control application software.
- Mobile Dr embedded system software.
- Mobile Dr generator control software.
- Utility model patent certificates for innovative mechanisms ensuring quality and safety.
Our Digital Mobile 500mA X-ray DR System Machine sets new standards in medical imaging, providing exceptional performance, reliability, and versatility for healthcare professionals.
Technical Parameters
| Item | Specification | ||
| 1.X- ray High voltage generator | |||
| 1.1 | standard output power：32kW max output power :40kW | ||
| 1.2 | mA range：10-400mA | ||
| 1.3 | Tube voltage range：40-150kV | ||
| 1.4 | mAs range ：0.1-500mAs | ||
| 1.5 | Load time range：0.001s～6.3s | ||
| 1.6 | Input voltage：336VDC±10% | ||
| 1.7 | High voltage transformer structure：The power frequency | ||
| 2.X-ray tube | |||
| 2.1 | Focus range：0.6/1.2mm | ||
| 2.2 | Anode heat capacity ：150kHu | ||
| 2.3 | Anode types: rotating anode, maximum speed: 3200 revolutions per minute | ||
| 2.4 | Pipe sleeve heat capacity: 1250kHu | ||
| 2.4 | The maximum voltage：150kV | ||
| 2.5 | The anode input power：Big focus:50kW ,Small focus:22kW | ||
| 2.6 | Anode angle 12° | ||
| 2.7 | The inherent filtration：1.3mm Al/75kV | ||
| 3. Collimator | |||
| 3.1 | The inherent filtration：1.2 mm Al /70 kV； | ||
| 3.2 | Collimator is equipped with LED lights（Bright 30s are automatically extinguished） | ||
| 3.3 | Collimator is built into measuring ruler | ||
| 4. The tube bracket structure | |||
| 4.1 | X-ray tube support way: cross arm | ||
| 4.2 | Tube focus distance to the ground：570㎜～1800㎜，±5％ | ||
| 4.3 | Telescopic Arm Length Range:710㎜～1240㎜ | ||
| 4.4 | Column Rotation Range :±270° | ||
| 4.5 | Tube Tilting Angle：±180° | ||
| 4.6 | Tube Vertical Rotation Angle：-30°～+90° | ||
| 4.7 | Collimator axial rotation ：±90° | ||
| 5. Detector | |||
| 5.1 | WIFI connection ，Amorphous Silicon ,whole panel technology | ||
| 5.2 | Detector valid exposure size ：420×344mm | ||
| 5.3 | Pixel size：150 µm | ||
| 5.4 | The effective camera size of the detector：14×17inch | ||
| 5.5 | Gathering matrix：≥2288×2784 pixels | ||
| 5.6 | Spatial resolution≥3.4lp/mm | ||
| 5.7 | Pixel gray level：≥14bit | ||
| 5.8 | Detector cooling mode: natural cooling | ||
| 5.9 | Imaging time:≤5s | ||
| 6. Digital image workstation MOC(V02.01.00) | |||
| 6.1 | CPU frequency：CORE i3 | ||
| 6.2 | Memory capacity：4GB | ||
| 6.3 | Hard drive capacity ：500 GB | ||
| 6.4 | Display size： 19 inch LCD touch screen | ||
| 6.5 | Display screen Maximum resolution≥1280×1024； | ||
| 6.6 | 64 bit Windows operation system | ||
| 7. Image acquisition software | |||
| 7.1 | Patient registration: acquisition, find the patient data, to prepare for the photography | ||
| 7.2 | Radio graphic examination：setting system parameters, exposure photography and get the image | ||
| 7.3 | Images display, image analysis, processing and output | ||
| 7.4 | Data management: managing patient data, leading in, leading out , batch file, etc in accordance with DICOM3.0 | ||
| 7.5 | Configure calibration: the system components such as flat-panel detector, such as tube for automatic configuration and calibration | ||
| 7.6 | System diagnosis: monitoring system status, diagnosis of the system fault | ||
| 8. Battery | |||
| 8.1 | Power supply way | ||
| 8.1.1 | storage battery supply | ||
| 8.1.2 | Battery capacity: Maximum 240 exposures, each time 100mAs, chest image dosage (exposure conditions: 120 kv, 100 mA, 20ms ) | ||
| 8.2 | There is no wall charge when exposed | ||
| 8.3 | Can support hand switch and remote control | ||
| 9. The machine parameters | |||
| 9.1 | Mobile mode: infinitely variable speed | ||
| 9.2 | Working mode: intermittent loading, continuous operation | ||
| 9.3 | Appearance size | ||
| 9.3.1 | Whole machine width：670 mm | ||
| 9.3.2 | Whole machine length：：1235 mm | ||
| 9.3.3 | Whole machine height：1825 mm | ||
| 9.4 | Whole weight ：518kg | ||
| 9.5 | Drive mode: dual motor drive, respectively control left and right driving wheel | ||
| 9.6 | Collision prevention: obstacle contact sensor | ||
| 10. External interface | |||
| 10.1 | Dual display interface (VGA/DVI) | ||
| 10.2 | Wireless network data transmission（WIFI） | ||
| 10.3 | Cable network interface | ||
| 10.4 | USB（4个） | ||
| 10.5 | Choose a chest rack | ||
| 10.6 | The selection of moving flat bed | ||
| 11. Aftersale service | |||
| 11.1 | The machine warranty 1 year | ||
| 11.2 | 1 set of complete operation and maintenance manual | ||
| 11.3 | Provide site application and service training | ||
| 11.4 | Free service hot line | ||
| 12. copyright certificate | |||
| 12.1 | DR service control application software | ||
| 12.2 | mobile Dr embedded system software | ||
| 12.3 | mobile Dr generator control software | ||
| 13. Related patents | |||
| 13.1 | Utility model patent certificate – a mobile digital medical X-ray photogram-system column rotating mechanism | ||
| 13.2 | Utility model patent certificate – a mobile digital medical X-ray system anti-collision mechanism | ||
| 13.3 | Utility model patent certificate – a mobile X-ray photographic system telescopic arm mechanism | ||
- Norminal power : 32kW
- Maximum power : 40kW
- Current range : 10-400mA
- Kvp range : 40-150Kvp
- Inverter frequency : 50kHz
- Current time product : 0.1-500mAs
- Focal spot: : 0.6mm/1.2mm
