Description
Introducing our advanced Veterinary C-Arm equipped with state-of-the-art specifications to elevate surgical imaging:
- Generator Technology: Employs High-Frequency IGBT Inverter Combinatorial technology for precise imaging outcomes.
- Output Power: Offers a robust 3.5kW power output, ensuring efficient performance during procedures.
- KV Range: Adjustable from 40 kV to 125 kV (IEC 60613-2010), providing versatility for various veterinary applications.
- mA Range: Ranges from 0.1 mA to 50 mA, allowing for fine adjustments tailored to specific diagnostic needs.
- Focal Spot Size: Features a focal spot size of 0.6 / 1.5 mm (IEC60336), ensuring detailed and accurate imaging.
- Total Filtration: Incorporates 2.7 mm Al equivalent total filtration (IEC60522) for enhanced image quality and safety.
- Target Angle: Set at a precise 12° angle for optimal imaging results.
- Cooling Method: Utilizes oil immersed cooling technology with convection oil cooling, ensuring efficient heat dissipation during prolonged use.
- Tube Protection: Includes built-in tube protection mechanisms for added safety and longevity.
- Exposure Control: Offers continuous mode and pulse mode exposure control options with adjustable settings for optimal imaging conditions.
- C-Arm: Features a mobile C-arm design for flexibility and ease of use in various veterinary settings.
- Displayer: Equipped with a 19-inch display for clear visualization of imaging results, with an optional touch screen feature for enhanced user interaction.
- Host: Host system specifications include a CPU of ≥3GHz, internal storage of ≥8G, and a hard disk capacity of ≥1T, ensuring seamless operation and ample data storage.
- Software: Supports both Chinese and English languages, with RIS/PACS compatibility (DICOM3.0) for seamless integration with existing systems.
- Image Viewing and Processing: Offers a range of image viewing and processing features including WW/WL, zoom, movement, rotation, contrast enhancement, noise reduction, and more.
- Advanced Measurement: Provides advanced measurement tools for precise diagnostics, including Norberg Angle, TPLO, TTA, TTA2, Hip Distraction, and VHS Scaling.
- Backup and Reporting: Allows for backup images in DCM, bmp, jpg formats, and supports report editing, printing, and film typesetting.
Our Veterinary C-Arm offers unparalleled imaging capabilities, making it an indispensable tool for veterinary surgeries and diagnostics.
Specifications
| Generator Technology : High Frequency IGBT Inverter Combinatorial | |
| Output Power | 3.5kW |
| KV Range | 40 kV – 125 kV(IEC 60613-2010) |
| mA Range | 0.1 mA – 50 mA |
| Focal Spot Size | 0.6 / 1.5 mm (IEC60336) |
| Total filtration | 2.7 mm Al equivalent (IEC60522) |
| Target angle | 12° |
| Cooling method | Oil immersed (70°C Max.) and convection oil cooling |
| Tube Protection | Yes |
| kV/mA setting | Continuous mode: Preset before exposure on. Adjustable during exposure on within 10ms response time. Pulse mode: Preset before exposure on for each pulse. Adjustable during exposure on for each pulse. |
| Exposure Control | External hardware signal trigger requesting. External hardware signal synchronize exposure ON/OFF. |
| C-arm | Mobile |
| Displayer | 19 inches Touch Screen : Optional |
| Host | CPU≥3GHz, Internal Storage≥8G, Hard Disk≥1T |
| Software | Language | Chinese, English |
| RIS/PACS (Support) |
DICOM3.0 | |
| Patient manageme nt | Emergency and General | |
| Examination | add | |
| Image View | WW/WL, Zoom, Movement, Rotation and Flip, ROI, Negative, Annotation, Mark, etc. | |
| Image process | contrast enhancement, Dislodge noise, etc. | |
| ABS | Automatic brightness stabilization | |
| LIH | Last Frame Holding | |
| Advanced measureme nt | Norberg Angle、TPLO、TTA、TTA2、Hip Distraction、VHS Scaling | |
| Backup Images | DVD DCM、bmp、jpg |
|
| Report | Editing, Printing | |
| Film | Typesetting, Printing |
Detailed Images
- maximum output power: : 3.5kw
- movement range : Vertical 400mm±8mm,Horizontal 200mm±4mm
- grid ratio : 10:1
- Focus: : 0.3/0.6mm
